dnp開發出新型的框架系統，可用于電視演播室、會議室和控制室中配備大屏幕的多屏應用。該框架系統專為現場組裝而設計，以有效降低成本，減少困擾。
更大的顯示系統意味著屏幕之間的接縫更少，所需的投影機更少，維修成本更低……選擇用大屏幕的顯示墻代替大量箱體的原因有很多。然而，由于顯示屏幕尺寸較大，在多屏幕應用場合，若要安裝2個、3個或4個大型光學屏幕以及框架系統，也是極具挑戰性的事情。
解決方案之一就是使用dnp的ViewFlex系統，因?yàn)樵谄聊怀鰪S時就已被預先框架組裝。但是，顯而易見，大型多屏幕結構的運輸和現場安裝既昂貴又困難。
為了解決此類物流難題，dnp現為大型屏幕設計了一個嶄新的框架系統，可讓客戶單獨運輸屏幕，并且可直接在安裝地點進行組裝。這項嶄新的框架系統允許屏幕水平并排尺寸由67” 到 200”的所有dnp單層屏幕。
此系統在屏幕邊緣處1mm的小孔中穿入細線接縫，使得每張屏幕能被巧妙地結合在一起，屏幕的物理拼縫為零，光學圖象間隙僅為2mm。接縫后方的遮光板避免了投影機投出的光線映在相鄰的屏幕上。屏幕固定于框架的頂部，這樣即使當溫度和濕度發生變化時，屏幕也可以得到伸展而不會彎曲。
如需了解更多技術規格和其它信息，請瀏覽
www.dnp.dk
或聯系當?shù)豥np經銷商。
New frame system for large screen walls
dnp has developed a new frame system for multi-screen applications with large screens in TV studios, conference rooms and control rooms. The frame system is designed for on-site assembly to reduce costs and hassle.
Larger displays with less seams, fewer projectors and lower maintenance costs… The reasons for using large screens in display walls in stead of a large number of cubes are many. But installation and framing of
multi-screen applications with two, three or four large optical screens can also be quite a challenge due to the huge display sizes.
A way to get around this is to use dnp´s ViewFlex system where several screens are delivered pre-framed from the factory. But it goes without saying, that transportation and on-site handling of a huge multi-screen structure can be both costly and difficult.
To solve these logistical problems, dnp now launches a framing system for large screens that allows individual transportation of screens and assembly directly at the installation site. The new system allows horizontal side-by-side framing of all dnp single-element screens in sizes from 67” to 200”.
A system of stitches of thin wire through 1mm holes at the edge of the screen keeps the screen elements neatly together with an image gap of only 2mm. Baffles behind the seams prevent light from the projectors from hitting neighbouring screens. And the screens are fixed at the top of the frame to allow expansion without bending due to changes in temperature and humidity
For more details and technical specifications see
www.dnp.dk or contact your local dnp distributor.
|
